OneLook.
Upload a pair of retinal photos, get a graded diabetic retinopathy report back — formerly RetinAI.
Overview
Diabetic retinopathy grading, without a specialist in the room
Diabetic retinopathy (DR) is graded on a 5-stage severity scale that normally requires an ophthalmologist reading a fundus photo. OneLook (built as RetinAI) grades both eyes from uploaded photos directly, no specialist required for the first pass.
It's a single-purpose classifier, not a general diagnostic platform — DR grading is the only thing the model does.
One DenseNet121, five severity classes
A DenseNet121 backbone (ImageNet-pretrained, top removed) feeds into global average pooling, dropout, and a 5-way softmax head — trained to output one of No DR, Mild, Moderate, Severe, or Proliferative DR. Left and right eyes are classified independently by the same model.
The app's own UI copy states the model runs at roughly 85% accuracy — the only accuracy figure that exists for this build; there's no separate benchmark or held-out test report backing it further.
- No DR
- class 0
- Mild
- class 1
- Moderate
- class 2
- Severe
- class 3
- Proliferative DR
- class 4
From prediction to a downloadable clinical report
Each eye's grade fills a DOCX report template alongside patient fields and the source images, plus a stage-specific canned recommendation — for example, Proliferative DR triggers a note that immediate treatment is essential to prevent vision loss.
The DOCX is converted to PDF (docx2pdf), rendered to an image for in-app preview (pypdfium2), and offered as a download — which is also why the report pipeline is Windows-bound (docx2pdf's conversion path depends on pywin32).
2nd place, 8th Hakeem Academy Competition
Built and shipped in a single session in August 2023 as a competition entry. Model weights are hosted externally rather than committed to the repo, so running it locally means downloading them separately before the first launch.
Method
Two retinal fundus photos go in, one DenseNet121 classifier grades each eye independently, and the two grades drive a templated clinical report.
- 01Upload
left + right fundus images
- 02DenseNet121
5-way softmax, per eye
- 03Report
DOCX template → PDF
Results
Stack
Reproduce it
$ git clone https://github.com/baselhusam/RetinAI.git$ pip install -r requirements.txt# download Y_new_1.h5 from the Google Drive link in the README$ streamlit run retinai.py
